|Alternative Part||Launch 3 WPS-727-03-NFC|
|Iso 9001:2008||Designed, manufactured and/or distributed under this quality management system|
|Rohs 2011/65/eu||Compliant by Exemption|
|Width||76.0 mm | 3.0 in|
|Height||43.0 mm | 1.7 in|
|Length||258.0 mm | 10.2 in|
|Shipping Weight||440.00 g | 0.97 lb|
|Split Loss||4.8 dB|
|3rd Order Imd||-150 dBc|
|Peak Power, Maximum||3 kW|
|Return Loss, Minimum||19.1 dB|
|Average Power, Maximum||300 W|
|Power Rating, Splitting||300 W|
|Operating Frequency Band||698 – 2700 MHz|
|Reflected Power, Maximum||300 W|
|3rd Order Imd Test Method||Two +43 dBm carriers|
|Dissipative Loss At Frequency Band||0.2 dB @ 698–2700 MHz|
|Inner Contact Plating||Silver|
|Outer Contact Plating||Trimetal|
|Relative Humidity||Up to 100%|
|Operating Temperature||-25 °C to +85 °C (-13 °F to +185 °F)|
|Ingress Protection Test Method||IEC 60529:2001, IP65|
|Width||61.00 Mm | 2.40 In|
|Height||25.00 Mm | 0.98 In|
|Length||227.00 Mm | 8.94 In|
|Net Weight||370.00 G | 0.82 Lb|
